PDRH3D28 Series 2.7μH~47μH SMD Shield Power Inductors Round Size

PDRH3D28 Series 2.7μH~47μH SMD Shield Power Inductors Round Size

China PDRH3D28 Series 2.7μH~47μH SMD Shield Power Inductors Round Size supplier
PDRH3D28 Series 2.7μH~47μH SMD Shield Power Inductors Round Size supplier PDRH3D28 Series 2.7μH~47μH SMD Shield Power Inductors Round Size supplier PDRH3D28 Series 2.7μH~47μH SMD Shield Power Inductors Round Size supplier PDRH3D28 Series 2.7μH~47μH SMD Shield Power Inductors Round Size supplier

Large Image :  PDRH3D28 Series 2.7μH~47μH SMD Shield Power Inductors Round Size

Product Details:

Place of Origin: Dongguan, China
Brand Name: P&Z
Certification: ISO9001:2015
Model Number: PDRH3D28 Series

Payment & Shipping Terms:

Minimum Order Quantity: 3000PCS
Price: To be confirmed
Packaging Details: Reel+Carton
Delivery Time: around 3-4 Weeks
Payment Terms: T / T in advance
Supply Ability: 1000k
Detailed Product Description

 PDRH3D28 Series 2.7μH~47μH SMD Shield Power Inductors Round Size



PDRH3D28 Series SMD Power Inductors

Features:

Inductance Range: 2.7μH~47μH

Temperature Range:-40℃~+125℃

★Quantity / Reel:3000pcs

Small products, Quadrate4.2mm Max, Height 1.7mm Type.

★The use of carrier tape package for SMT reflow soldering process

★Widely use in DC-DC converter/LCD TV/Notebook/PDA/MP3 & MP4 player/Digital camera/DVD etc.

★Design to customer requirement.

Electrical Characteristics:

Part Number

Test Condition

Inductance(μH)

Tolerance(%)

D.C.R(Ω)Max.

RatedCurrent(A)

PDRH3D28-3R3N

100KHz/0.1V

3.3

±30

0.088

2.00

PDRH3D28-4R7N

100KHz/0.1V

4.7

±30

0.124

1.65

PDRH3D28-6R8N

100KHz/0.1V

6.8

±30

0.145

1.24

PDRH3D28-100N

100KHz/0.1V

10

±20

0.158

1.05

PDRH3D28-120M

100KHz/0.1V

12

±20

0.280

0.90

PDRH3D28-150M

100KHz/0.1V

15

±20

0.213

0.85

PDRH3D28-220M

100KHz/0.1V

22

±20

0.335

0.80

PDRH3D28-330M

100KHz/0.1V

33

±20

0.481

0.65

PDRH3D28-470M

100KHz/0.1V

47

±20

0.599

0.50

PDRH3D28-101M

100KHz/0.1V

100

±20

1.140

0.45

1.Inductance is measured with a LCR meter:HP4284A & 3532-50 or equivalent.
2.D.C .R is measured with a Digital Multimeter TH2512B or equivalent.
3.Rated Current:The rated current is the current at which the inductance decreases by 25% from the initial value
or the temperature rise is △T=40℃ ,whichever is smaller(Ta=20℃).

                            PDRH3D28 Series 2.7μH~47μH SMD Shield Power Inductors Round Size

Acceptable customers design cust
